Allied Maxcut 20mm Shank 7XD 91 D GEN3SYS Flanged Flat Shank Spade Drill Body

Introduction

GEN3SYS XT replaceable insert high penetration drilling system has been designed to provide high speed production machining beyond the capabilities of the T-A drilling system. The product offering consists of various grades, geometries and coatings available to suit the most demanding applications.

Brand :Allied Maxcut

Drill Insert Range (mm) :12 – 12.99

Holder Type :Standard

Manufacturer Part Number :60712S-20FM

Maximum Cutting Depth (mm) :91

Additional Information :Triangle is a safety hazard symbol. It alerts you to potential safety hazards that can cause tool failure and serious injury. NOTICE means that failure to follow the precautions in this message could result in damage to the tool or machine but not result

Features & Benefits : Excellent chip control
Improves hole quality and surface finish
Provides maximum durability and stability
Helical (machining centre) flute
Carbide holder material

Length of Cut (mm) :91

Diameter Range (mm) :12.00 to 12.99

Flute Type :Straight (Lathe)

Shank Type :Flanged Flat Shank

Overall Length (mm) :168.5

Diameter :7x

Shank Length (mm) :42

Body Length (mm) :118.5
